• These are used for redrawing into Wires / Strips for manufacture of Cables, Conductors, Transformer Wires / Strips and various hardware / General Engg. Components.
| SPECIFICATIONS | |
| 1. Diameter : | 9.5 + 0.5 mm |
| 2. Quality : | EC Grade as per IS 5484 in as manufactured conditions ie., M Condition |
| 3. Mechanical properties : | 8.5 to 13.6 Kg/mm2 |
| Tensile Strength : | 9 to 14% on 250 mm Gauge Length. |
| Elongation | |
| 4. Electrical properties : | |
| Conductivity : | 60 to 61.5% IACS |
| 5. Coil Weight : | 2000 + 250 Kgs. |
| 6. ID : | 550 mm |
| 7. OD : | 1800 mm approx. |
| 8. Width : | 900 mm |
